Manual TTR Slitter RSDS4

Manual TTR Slitter RSDS4
Send Inquiry
Product Code : 03
Price And Quantity
  • Minimum Order Quantity
  • 1
  • Unit of Measure
  • Piece/Pieces
  • Price Range
  • 38000 - 100000 USD ($)
Product Description

Since 2010, we have been successfully engrossed in manufacturing, exporting and supplying supreme quality TTR Slitter machine. This slitter is manufactured under the supervision of our talented professionals in tune with the set quality standards at our advanced manufacturing unit. It is based on PLC operations for slitting ribbons of various width. Giving high working speed to achieve maximum productivity, the provided Manual Thermal Transfer Ribbon (TTR) slitting equipment can be availed at marginal prices from us.

Features:
1) Easier operations
2) Longer service life
3) High performance
4) Needs least maintenance

Machine Technical Data (RSDS4)

Jumbo roll width

650mm~1050mm

Film thickness

4~20um

Jumbo roll diameter

650mm in max.

Working speed

20~400 m/min

Jumbo roll core dia.

3inch /6inch

Finished roll width

20mm minimum

Jumbo installation

Without shaft

Finished roll core

1inch / 1/2inch

Power


AC 380V(220V) 3P+N+PE

Finished roll dia.

135mm maximum Length approx.1800m

Main engine power

7KW

Leader table

Manual

Air power

0.6~0.8MPa

Blade

Blade holder

Razor blade

Magnetic blade holder,35sets

Weight

2000kgs

Dimension

2360mm*2110mm*1700mm

Trade Information
  • FOB Port
  • XIAMEN
  • Payment Terms
  • Telegraphic Transfer (T/T), Letter of Credit at Sight (Sight L/C), Letter of Credit (L/C), Cash in Advance (CID), Cash Advance (CA), Cash Against Delivery (CAD)
  • Supply Ability
  • 10 Per Month
  • Delivery Time
  • 45-60 Days
  • Packaging Details
  • Size: Leader part: 2.40*0.90*1.47 Main machine: 2.25*1.1*1.97 Weight :2150KG
  • Main Export Market(s)
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • Main Domestic Market
  • All India
  • Certifications
  • TUV CE
